Attachement Push Pull Forklift

Accueil / Toutes les pièces jointes / Attachement Push Pull Forklift

Attachement Push Pull Forklift
A push-pull forklift attachment is a material handling device designed to move long and heavy loads with ease. It is attached to the forklift and helps in pushing and pulling large and heavy loads, making the movement of goods from one place to another much easier. This attachment is especially useful for handling long and narrow loads such as pipes, steel beams, and sheets.

The push-pull attachment is made up of two arms that are attached to the forklift's tines. These arms can be extended to accommodate the length of the load being transported. The arms also have rollers on their ends that make it easier to move the load. The rollers can be adjusted to the desired height, making it possible to transport loads of different heights and sizes.

This attachment is easy to install and operate. It can be easily attached to the forklift and removed when not in use. The arms can be extended or retracted to accommodate the size of the load being transported. The attachment also comes with hydraulic control valves that make it possible to control the speed and direction of the load.

The push-pull forklift attachment is ideal for handling long and narrow loads such as pipes, steel beams, and sheets. It reduces the risk of damage to the load and the environment, as it allows for precise control over the movement of the load. The attachment also helps to increase productivity by reducing the amount of time and effort required to transport the load.

In conclusion, the push-pull forklift attachment is a useful tool for transporting long and heavy loads. It makes material handling easier, reduces the risk of damage to the load and the environment, and increases productivity. This attachment is a must-have for any company that handles long and narrow loads.

Avantages du produit

HUMAI forklift push/ pull forklift attachment with China Xinchai C490 engine, hydraulic transmission,USA EATON hydraulic assisted steering valve,SHIMADZU oil pump,full suspension chassis.It is widely used to handing all kinds of goods,such as pallet,steel,brick etc.Shantui has cooperated with KOMATSU more than 30 years,all the product was made under KOMATSU standard.

Vidéos

Moteur
Modèle
HUAMAI C490
Puissance nominale
40/2650
Kw / rpm
Couple nominal
165/1800
N · m / rpm
Nombre de cylindre
4
Bore × course
90 × 105
mm
Déplacement
2.7
L
Dimensions
Hauteur de levage
3000
mm
LxWxH (avec / sans fourche)
3779 (2709) x1226x2140
mm
Rayon de braquage
2450
mm
Angle d'inclinaison du mât (F / R)
6/12
Diplôme
Performance
Vitesse de déplacement (à pleine charge / à vide)
19/20
Km / h
Vitesse de levage (avec / sans) charge
420/450
mm / sec
Max.gradeability
20
%
Poids propre
4560
Kg
Roue et pneus
De face
28 × 9-15-14PR
Arrière
6.50-10-10PR
Empattement
1700
mm
Hauteur libre (mât)
110
mm

Détails rapides

Condition: Nouveau
Lieu d'origine: Xiamen, Chine (continentale)
Nom de marque: HUAMAI
Numéro de modèle: HUAMAI30
Type: transpalette motorisé
Puissance Souce: Moteur Diesel
Capacité de chargement évaluée: 3000kg
Max. Hauteur de levage: 8000mm
Min. Hauteur de levage: 3000mm
Longueur de la fourche: 1070mm
Largeur de la fourche: 122mm
Dimensions hors tout: 3829x1226x2140mm
Certification: ISO9001 / ISO14001 / CE
Service après-vente fourni: Ingénieurs disponibles pour entretenir des machines à l'étranger
Accseeory: pousser / tirer
Taille de fourche: 1070 * 122 * 40mm
Centre de charge: 500 mm
Pneu: pneumatique
Type d'alimentation: Diesel
Couleur jaune
Empattement: 1700mm
Batterie: 12V / 60Ah
Capacité du réservoir d'huile: 50 litres
pression de fonctionnement: 17.5Mpa
